Stryker 1069 Operation Manual

Stretcher Operation
4
OPERATING BASE CONTROLS – SIDE CONTROL WITH UNI–LOWER PEDAL
A
Pump to raise litter.
B
Depress in the center of pedal (B) to lower
C
Depress the side of pedal (B) closest to the
E
Brake and Steer functions (foot end)
F
Brake and Steer functions (head end)
E
F
A
A
D C
CD
B
B
both ends of the stretcher together.
foot end of the stretcher to lower the foot end.
D
Depress the side of pedal (B) closest to the
head end of the stretcher to lower the head end.
