EN-11
DRAFT
4� If required, connect the hand control, footswitch, and/or USB drive according to the interconnection
diagram�
Note: Stryker recommends using the SIDNE USB2�0 Flash Disk, 512MB (P/N 0105-201-529)�
Note: The pump’s screen will display the specic components that are connected when the device is
powered on�
Caution
• Do not connect an ethernet cable to the auxiliary port�
• Turn the connector of the hand control and footswitch so that the red dot points up�
• Do not thread or twist the cable connector for insertion or removal� It is a push/pull connector
and may be damaged by twisting it into or out of place�
5� For tubing connection instructions, refer to the CrossFlow Inow and Outow Cassette Tubing and the
CrossFlow Day-Use Inow Cassette and Patient-Use Tubing manuals�
