0703-001-700 Rev-C EN
www.stryker.com 25
BUTTON NAME FUNCTION
Close
CLOSE ERROR MESSAGE Touch the button to exit or close an error message.
Back
BACK Touch the button to exit and return to the previous screen.
NOTIFICATION
Touch the button to access LOW PRIORITY alarm information. A
drop-down list of one or more messages will appear.
ERROR
Touch the button to access MEDIUM PRIORITY alarm
information. A drop-down list of one or more messages will
appear.
Quick Wash
QUICK WASH
Touch the button to select the QUICK WASH cycle option. A
cycle description and when the cycle was last performed are
provided.
Normal Wash
NORMAL WASH
Touch the button to select the NORMAL WASH cycle option. A
cycle description and when the cycle was last performed are
provided.
Extended Wash
EXTENDED WASH
Touch the button to select the EXTENDED WASH cycle option.
A cycle description and when the cycle was last performed are
provided.
Start
START
Touch the button to initiate the QUICK WASH cycle, the NORMAL
WASH cycle, or the EXTENDED WASH cycle (Figure 46). See
Table 18 Docking Cycle Options.
Cancel
CANCEL
Touch the button to stop docking and prepare the rover for
release. The RELEASE FROM DOCKer button will appear.
Abort to Quick Wash
ABORT TO QUICK WASH
Touch the button to interrupt the NORMAL WASH or EXTENDED
WASH cycle and initiate the QUICK WASH cycle. This option
is only available during the early stages of the NORMAL WASH
cycle or EXTENDED WASH cycle.
Release From Dock
RELEASE FROM DOCK(er)
Touch the button, available after the cycle is complete or a
cancellation, to disconnect the rover from the docker.
0000160552, Rev. C Effective Date: Nov 25, 2015 1:43:15 PM
Print Date: Nov 25, 2015 02:19:13 PM
