Stryker Neptune 3 User Manual

0703-001-700 Rev-C EN
www.stryker.com 27
Table 5 – Suction Limit Ranges and Colors
This table defines the suction limit range and associated
color. Color indicators are shown on the top display, the
main display, and by a suction range indicator above each
manifold receptacle. See Section 6 Features.
COLOR
SUCTION
LIMIT
RANGE
VALUE
(mm-Hg)
INCREMENTS
(mm-Hg)
Orange
MAXimum 520 Not Applicable
Orange
HIGH 120 to 520 20
Yellow
MEDium 80 to 115 5
Green
LOW 50 to 75 5
White
OFF 0 Not Applicable
Table 6 – Title Area Colors
This table defines the color used in the title area of the
control screen.
COLOR DEFINITION
Green Indicates suction is ON
Gray Indicates suction is OFF
White Indicates suction is PAUSED
Table 7 – Button Colors
This table defines the color of buttons used on the control
screen.
COLOR DEFINITION
Green
Indicates a START or CONFIRM condition or
function
Red Indicates a STOP function
Table 8 – Manifold Symbol Colors
This table defines the color of the manifold symbol used
on the control screen.
COLOR DEFINITION
White Indicates NEW manifold
Pink Indicates USED manifold
Table 9 – Canister Symbol Colors
This table defines the color of the canister symbol used
on the control screen.
COLOR DEFINITION
White Indicates fluid volume SINCE last reset
Grey Indicates fluid volume BEFORE last reset
Blue Indicates fluid volume ALMOST FULL
Yellow Indicates fluid volume FULL
Table 10 – Message Area Colors
This table defines the color of the notification and error
message areas used on the control screen.
COLOR DEFINITION
Blue Indicates LOW PRIORITY alarm
Yellow Indicates MEDIUM PRIORITY alarm
Table 11 – Audible Event Indicators
This table describes the audible indicators associated
with each type of system event.
TYPE INDICATION TRIGGER
Initial
Startup
Chime tone
Startup screen with
progress bar
Button
Touch
Click tone
Main display button
actuation
Task
Complete
Ding tone
Valid manifold
installed successfully
Notification
Two declining
tones
Any LOW PRIORITY
alarm
Error
Three slow tones,
three times
Any MEDIUM
PRIORITY alarm
NOTE: See Table 16 High Suction Visual and Audible
Indicators and Table 17 Fluid Volume Indicators.
Table 12 – Abbreviations
This table defines abbreviations used in this manual and
on the equipment.
NAME DEFINITION
HEPA High Efficiency Particulate Air
IR Infrared wavelength light
IV Intravenous
LED Light emitting diode
mL Milliliters
mm-Hg Millimeters of mercury
OR Operating room
ULPA Ultra Low Penetration Air
0000160552, Rev. C Effective Date: Nov 25, 2015 1:43:15 PM
