0703-001-700 Rev-C EN
www.stryker.com 55
Mass: 131 kg [288 lb] - collection canisters empty (prefill only)
155 kg [341 lb] - collection canisters full
Volume: 24-liter capacity (combination of 4-liter and 20-liter canisters)
Volume Measurement
Accuracy:
4-liter canister, ± 50 mL
20-liter canister, ± 150 mL
NOTE: Volume measurement accuracy specified does
not account for fluid evaporation or an inclined plane of
operation that exceeds the specified range.
IV Pole Capacity: 12000 mL or 3000 mL per IV pole hook; for example four three-liter (3000 mL) fluid bags
Inclined Plane of
Operation:
± 2.5 degrees
Equipment Type:
Type CF Applied Part
Equipment Classification: Class I Medical Electrical (ME) Equipment
Ingress Protection (IP): IPX0
LED Classification - IR
Communication Window:
WARNING: INVISIBLE LED RADIATION
DO NOT VIEW DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS 1M LED PRODUCT — Viewing the laser output with certain optical instruments
(for example, eye loupes, magnifiers, and microscopes) within a distance of 100 mm
may pose an eye injury hazard.
Ground Type:
Protective Earth (ground); when connected to facility power
Environmental
Conditions:
Operation Storage and
Transportation
(before initial use)
Storage and Transportation
(after initial use)
Temperature Limitation:
Humidity Limitation:
Atmospheric Pressure
Limitation:
0000160552, Rev. C Effective Date: Nov 25, 2015 1:43:15 PM
Print Date: Nov 25, 2015 02:19:13 PM
