Stryker S3 MedSurg 3002 User Manual (English)

Questions and Answers:

L
Lawrence DunlapAug 2, 2025
How to troubleshoot no power to Stryker S3 MedSurg 3002 Medical Equipment bed?
- J
  jwilsonAug 2, 2025
  If your Stryker Medical Equipment bed has no power, there are several steps you can take: 1. First, check the power cord connections at both the wall and the bed to ensure they are secure. 2. Next, examine the circuit breakers located under the Litter/Fowler section on the patient’s left side. If a breaker has tripped, reset it by pushing it in. 3. Then, check for 230VAC at J1 on the power supply, Pin 1 and 2. 4. Also, check for DC voltages on J2 (Pins 1, 2, 3 & 6) on the power supply. 5. Check for 230VAC at connector O on the CPU board. 6. If the CPU board was replaced, reconfigure the bed by resetting the Bed Type, Bed Options, Serial Number, Burn-in Limits (Fowler and Height), and calibrating the scale. 7. Finally, verify the bed's function.
W
Wesley EvansAug 5, 2025
What to do if Stryker S3 MedSurg 3002 bed has no bed down motion?
- E
  eruizAug 6, 2025
  If the Stryker Medical Equipment bed is not moving down, you can try the following: 1. Enter diagnostics and press the bed down button. 2. Check for 5VDC on TP 9 (HL) and TP 7 (FL), referencing the ground test point while pushing the bed down button. 3. Check for 230VAC power on connector N (HL) and G (FL), pin 1 white and pin 3 black, of the CPU board while pressing bed motion up. Finally, verify the bed's function.
S
Steven EstradaAug 10, 2025
What to do if Stryker Medical Equipment bed has no bed up motion?
- W
  welchangelicaAug 10, 2025
  If the Stryker Medical Equipment bed is not moving up, you can try the following: 1. Enter diagnostics and press the bed up button. 2. Check for 5VDC on TP 10 (HL) and TP 8 (FL) on the CPU board, referencing the ground test point while pushing the bed up button. 3. Check for 230VAC power on connector N (HL) and G (FL), pin 1 white and pin 6 red, of the CPU board while pressing bed motion up. Finally, verify the bed's function.
D
dawsonphillipAug 15, 2025
What to do if Stryker S3 MedSurg 3002 Medical Equipment bed has no Gatch down motion?
- J
  jane32Aug 15, 2025
  To troubleshoot a Stryker Medical Equipment bed with no Gatch down motion: 1. Check for 5VDC on TP4 on the CPU board, referencing the ground test point while pushing the fowler down button. 2. Check for 230VAC on connector GG, Pin 1 (white) and pin3 (red), of the CPU board while pressing Fowler down. Finally, verify the bed's function.
J
Justin DanielsAug 18, 2025
What to do if Stryker S3 MedSurg 3002 Medical Equipment bed has no Gatch up motion?
- J
  Jose RichardAug 18, 2025
  To troubleshoot a Stryker Medical Equipment bed with no Gatch up motion: 1. Check for 5VDC on TP 3 on the CPU board, referencing the ground test point while pushing the fowler up button. 2. Check for 230VAC on connector GG, Pin 1 (white) and pin 2 (black), of the CPU board while pressing Fowler up. Finally, verify the bed's function.
D
dawnlewisAug 23, 2025
What to do if Stryker S3 MedSurg 3002 bed has no Fowler up motion?
- R
  Rita IrwinAug 23, 2025
  If the Fowler on your Stryker Medical Equipment bed isn't moving up, here’s what you can check: 1. Verify 5VDC on TP 6 on the CPU board, reference ground test point while pushing the gatch up button. 2. Check for 120VAC on connector CC, pin 1 (black) and pin 3 (white), of the CPU board while pressing gatch up. After these checks, verify the bed function.
M
Mark PetersonAug 27, 2025
What to do if Stryker S3 MedSurg 3002 Medical Equipment bed has no Fowler down motion?
- V
  Veronica CarrollAug 27, 2025
  If the Fowler on your Stryker Medical Equipment bed isn't moving down, here’s what you can check: 1. Verify 5VDC on TP 5 on the CPU board, reference ground test point while pushing the gatch down button. 2. Check for 230VAC power on connector CC, pin 2 (red) and pin 3 (white), of the CPU board while pressing gatch down. After these checks, verify the bed function.

Stryker S3 MedSurg 3002 Specifications

General

Weight Capacity	500 lbs (227 kg)
Power Requirements	120 V AC, 60 Hz
Battery Backup	Yes
Type	Hospital Bed
Length	84" (213 cm) overall
Mattress Platform Length	84 inches
Mattress Platform Width	36 inches
Backrest Angle	0 to 60 degrees
Knee Gatch Angle	0 - 30 degrees
CPR Release	Yes
Side Rail Options	Full, half, or no side rails
Finish	Powder Coated
