15
Using the On-Screen Display
e device on-screen display helps navigate through various device menus.
1. Press the Rotary Control to activate the on-screen display (OSD) menu.
2. Rotate the Rotary Control to move up or down through the menu.
e parameter will be highlighted when selected.
3. Press the Rotary Control to enter the next level OSD.
4. Rotate the Rotary Control to increase or decrease the value of the
selected parameter, or to make a selection on dierent options.
5. To exit the OSD menu screen from the second — or third — level OSD
menu, select the Exit option. To completely exit the OSD, press and hold
the Rotary Control. If no keys are pressed, the OSD will automatically
exit.
6. While the OSD menu is deactivated, rotate the Rotary Control to
activate the input signal selection menu. e current input signal will
be indicated by a dot. Rotate the Rotary Control to select the preferred
input signal.
Stryker Camera Preset Modes
Camera
Resolution
(H × V)
Horizontal
Frequency
(KHz)
Vertical
Frequency
(Hz)
988 1024 × 768 49.09 59.90
988i 1024 × 768 41.25 50.00
1088/SDC Pro2 1024 × 768 50.03 60.00
1088i/SDC Pro2 1024 × 768 41.10 50.00
1088/1188/SDC HD 1280 × 1024 64.02 60.10
1088i/1188i/SDC HD 1280 × 1024 59.99 50.00
1188w720 1280 × 720 45.00 60.00
1188iw720 1280 × 720 37.50 50.00
