22
1. Route the video output 1 from the camera to the input on the SDC or
SIDNE.
2. Route the video output 1 from the SDC or SIDNE to the input on the
transmitter.
3. Connect the DVI output from the transmitter to the primary display.
4. Connect the C-video input on the display to the C-video output on a
VCR or printer.
5. Connect the C-video input on the VCR or printer to the C-video output
on the camera.
6. Link an auxiliary display to the transmitter. (Link the display and
transmitter each time the display is powered on.)
Linking the Transmitter to an Auxiliary Display
Caution Equipment that employs RF communications may aect
the normal function of the transmitter. When choosing a
location for the transmitter, consult the “Electromagnetic
Compatibility” section of this manual to ensure proper
function.
In accordance with patient privacy laws, do not transmit
personal patient information, such as EKG, EEG, patient
name, or patient ID, over the wireless signal.
e transmitter functions on one of eight wireless 20 MHz channels in the
4.9 – 5.9 GHz spectrum. As necessary, remove other wireless devices from the
environment, such as cordless phones and 802.11a/n routers to make channels
available for the transmitter and display.
To link the display to the transmitter and thereby enable wireless
communication, any WiSe™ HDTV Transmitter token will suce.
