- 12 –
Stuart Turner reserve the right to amend the specification in line with its policy of
continuous development of its products.
*Note: The maximum pressure that can be applied to the pump under any
installation conditions.
**Note: With footvalve fitted.
5.11 Noise: The equivalent continuous A-weighted sound pressure level at a
distance of 1 metre from the pump does not exceed 70 dB(A).
5 TECHNICAL SPECIFICATION
Pump Model
PH 35 ES
50 Hz
46563
PH 35 ES
50 Hz
46451
PH 45 ES
50 Hz
46564
PH 45 ES
50 Hz
46454
General
Guarantee 2 years
WRAS approval Approved materials
Approvals CE
Features
Pump type Peripheral
Priming vent plug
ü ü ü ü
Typical noise 61 dB(A) 64 dB(A)
Materials
Pump body Brass
Impeller Brass
Mechanical seal
EPDM / PTFE /
Al. Oxide
Viton / Carbon /
Silicon Carbide
EPDM / PTFE /
Al. Oxide
Viton / Carbon /
Silicon Carbide
Performance
Maximum head – closed valve 3.0 bar / 30 metres 4.2 bar / 42 metres
Performance @ 9 l/min 2.0 bar / 20 metres 3.2 bar / 32 metres
Performance @ 18 l/min 1.2 bar / 12 metres 2.3 bar / 23 metres
Maximum flow 32 l/min 40 l/min
Minimum static inlet pressure 0.05 bar (0.5 metres)
Maximum static inlet pressure 1.4 bar (14 metres)
Maximum working pressure* 600 kPa (6 bar)
Maximum viscosity 50 secs redwood no. 1 9.5 centistokes
Max. ambient air temperature (continuous) 40
o
C 40
o
C 40
o
C 40
o
C
Max. ambient air temperature (intermittent) 50
o
C n/a 50
o
C n/a
Min / Max water temperature Min 4
o
C / Max 80
o
C
Maximum suction lift** 4.6 metres
Connections Pump connections G 1 female
Motor
Type Induction, auto-reset thermal trip
Duty rating Continuous (S1) @ 5 l/min and above
Electrical
Power supply (Vac/Ph/Hz) 230 V a.c. / 1 / 50 Hz
Power consumption – P1 450 Watts 665 Watts
Current – full load 1.95 Amps 2.9 Amps
Fuse rating 5 Amps
Power cable length 1.5 metres (pre-wired)
Physical
Enclosure protection IP44
Length 241 mm 257 mm
Width 132 mm
Height – excluding hoses 169 mm
Weight – including fittings 4.6 Kg 6.2 Kg
