UP, DOWN, ENTER/EDIT
The
UP
and
DOWN
buttons
are
used
to
scroll
through
the
FUNCTION
selections
while
in
edit
mode.
Depressing
the
ENTER/EDIT
button
enters and
exits
the
EDIT
mode.
While
in
edit
mode
a
LED
is
lit
next
to
the
corresponding
FUNCTION
that
is presently selected
for
editing.
Using
the
UP/DOWN
buttons
will
cause
the
LED
to
scroll through
the
FUNCTION
selections.
10
KEY
PAD;
(H)
AND
(-),
(ON)
AND
(OFF)
This is the area where you enter desired parameters for selected FUNCTIONS being edited. The
numerical keypad, (H) and (-), (on) and (off) are assigned to correspond to the keys of the
central octave of the KEYBOARD.
While
in
EDIT
MODE
these
keys
now
function
as
our data entry method and
will
not
transmit
note information.
In
other words, while
in
EDIT
MODE
the
entire keyboard is
disabled
and
will
not
transmit
note
information
until
you
exit
the
EDIT
MODE.
MIDI
CHANNEL
Used
to
select which
MIDI
channel each
of
the
(2)
ZONES
will
transmit
its
information
on.
To
access
this,
parameter
enter
EDIT
mode
by selecting
ENTER/EDIT.
Select desired
ZONE
for
editing
by depressing
its
corresponding
ZONE
switch.
Use
the
UP/DOWN
buttons
to
select
MIDI
CHANNEL
function.
You
now
enter
a
one or
two
digit
value
using
the
10
key keypad
to
set
the
ZONE'S
MIDI
transmit
channel. Exit
the
EDIT
mode by
depressing the EDIT/ENTER button. In exiting the EDIT mode you store the new information
automatically
in
the
SL-161/SL-61
Master Controller's memory and enable
the
keyboard
ZONE
to
play
and transmit information on the new selected MIDI channel. In order to play and transmit on
a
desired
ZONE,
select
the
corresponding
ZONE
switch
while
in
play
mode
so
that
its
LED
is
lit.
The
ZONE
switch
will
toggle
to
turn
ZONE
on and
off.
BANK SELECT
Used
to
transmit
or
initiate
a
BANK
CHANGE
message
on
a
given
zone.
After
selecting
and
assigning
the
MIDI
CHANNEL,
press
DOWN
button
to
switch
to
BANK
SELECT.
This mode allows
you to change the sound bank of your synth module or external sound source.
The
reception
protocol
for
BANK
SELECT
depends on
the
type
and
make
of
the
sound module
you are transmitting to and can vary from manufacturer to manufacturer. If the synth module
you
are
using requires only "Control
32"
then you
will
have
to
only enter
the
bank number you
wish to select. If your module requires a more complete protocol (Control 32+ Control 0) then
you need to enter Control 32 and then press the key corresponding to the "H" (represents
Higher part of Bank Change Byte) symbol (same as minus key). Then enter the desired num-
ber for Control 0. The key sequence would be as follows: enter 32, then the (-) minus key
which also has the (H) symbol labeled above it, then the bank number to change to.
PROGRAM CHANGE
Used
to
select
a
PATCH
NUMBER
or
PROGRAM
CHANGE
for
a
specific
ZONE.
To
access
this
para-
meter you
first
turn
on
the
desired
ZONE
by selecting and pressing
its
corresponding
ZONE
switch, then enter EDIT mode by selecting ENTER/EDIT.
Select desired
ZONE
for
editing
by depressing
its
corresponding
ZONE
switch.
Now
use
the
UP/DOWN buttons to select the PROGRAM CHANGE function. Enter the desired number of your
patch selection on the keypad (MIDI Program change messages are from 1 to 128). Exit the
EDIT mode by depressing the EDIT/ENTER button. In exiting the EDIT mode you store the new
information
in
the
SL-161/SL-61's
Master
Controllers memory,
transmit
the
selected patch number
and enable the keyboard to play the new selected PROGRAM CHANGE.
SPUn-
Used to select the range of keys to be active for a specific ZONE. To set the Key Range or SPLIT
for
a
ZONE,
enter
the
EDIT
MODE
by pressing
ENTER/EDIT,
toggle
up or down
till
the
light
next
to
SPLIT
is
lit.
Press
the
ZONE
button
for
the
ZONE
you wish
to
set,
now
press
the
desired
lowest key on the KEYBOARD and then the highest key on the KEYBOARD to define the range
of
keys
to
be active
in
that
ZONE.
Exiting
the
EDIT
MODE
stores
the
information
and
all
other
edit
parameters
that
were changed.
The
ranges
of
keys
can be any one note (by
hitting
the
