35 © STULZ S.p.A. – all rights reserved EN/06.2016/i01
WPA EXPLORER ORIGINAL INSTRUCTIONS
WPA060 WPA070 WPA080 WPA090 WPA100 WPA110
min max min max min max min max min max min max
Water flow [m³/h] 12 42.5 12 46.6 12 53.3 12 58 12 61.2 12 75.9
Pressure drop [kPa] 10.15 100 8.60 100 6.39 100 5.28 100 4.72 100 3.40 100
WPA120 WPA140 WPA160 WPA180 WPA200
min max min max min max min max min max
Water flow [m³/h] 12 83.8 12 89.2 54 133.0 64 67.9 64 67.9
Pressure drop [kPa] 10.15 100 8.60 100 17.4 100 15.8 140 15.8 140
A B C D E F G
[°C] AT AT AT AT AT AT AT
BASE
WPA060 57 55.5 52 46 0 -5 -10
WPA070 57 55 50 44 -3 -9 -10
WPA080 57.5 55.5 52.5 47 -7 -10 -10
WPA090 57 54 51 45 -10 -10 -10
WPA100 57 54 50 43 -10 -10 -10
WPA110 58 57 54 48 -6 -10 -10
WPA120 57.5 55 51.5 45.5 -8 -10 -10
WPA140 57 53.5 51 44 -10 -10 -10
WPA160 57.5 56 52.5 47 -7 -10 -10
WPA180 55 51 50.5 43.5 -10 -10 -10
WPA200 55 50 49 41.5 -10 -10 -10
A B C D E F G
[°C] AT AT AT AT AT AT AT
LOW NOISE
WPA060 57 54 50 44 0 -5 -10
WPA070 57 54 48 41 -3 -9 -10
WPA080 57.5 53 50 45 -7 -10 -10
WPA090 56 52 49 41.5 -10 -10 -10
WPA100 57.5 56 54 46.5 -3 -8 -10
WPA110 57 56 52 44.5 -6 -10 -10
WPA120 57 53.5 49.5 42 -8 -10 -10
WPA140 56.5 54.5 51.5 45.5 -10 -10 -10
WPA160 56 54.5 50.5 44 -7 -10 -10
WPA180 56 53 51 47 -7 -10 -10
WPA200 55 51 50 42.5 -10 -10 -10
A B C D E F G
[°C] AT AT AT AT AT AT AT
FREE COOLING
WPA060 57 54 50 43 0 -6 -10
WPA070 57 54 49 40 -4 -10 -10
WPA080 57 55 51 45.5 -7 -10 -10
WPA090 57 53 49.5 43 -10 -10 -10
WPA100 57 51 48 40.5 -10 -10 -10
WPA110 59 56.5 51.5 45.5 -3 -10 -10
