WPA EXPLORER ORIGINAL INSTRUCTIONS
7. Commisioning
WARNING
• The unit must be installed and connected in accordance to the manual, especially with the
chapter "6 Installation" at page 52, before initial commissioning.
• Only authorized and certified personnel is allowed to commission the unit
7.1 Preparation
WARNING
• Power supply of the customer must be switched off
• Check that the unit main-switch is in OFF position
Inspect for visible damages which can affect proper operation of the chiller, and in particular:
• check for transport/handling/installation damages
• check the coil surfaces (on free cooling and condenser coils)
• check that all components are installed in a proper way and are correctly fixed
• check if the insulations are correctly installed and without any damages
• corrosions
• verify that all documents are available (manual part I°, part II° and electronic controller manual)
Check the refrigerant circuit: connect your own gauges and check the tightness of the refrig-
erant circuits according to the outside temperature of the refrigerant pressure. In case off leak-
age please contact the manufacturer.
Check the fans. Be sure that the fan guards are all correctly installed, and the fans are not
damaged.
Check compressor oil level see "8.3.9 Compressor" at page 71
Check correct power connection cabling. Be sure that all the connections are correctly
installed and fixed (see "6.8 Electrical connection" at page 60). Verify the earth connections
(see "6.10 Position of the electrical connections" at page 61).
Check water system. Verify the flow direction is according the IN/OUT connections on the
refrigerator (see "5.5 Dimensional drawings" at page 45).
• check the hydraulic connection
• check if the water system is filled up with water/glycol and the glycol concentration according
to the "6.4 External water circuit" at page 56
• ensure that all valves are open
• check if there is a water filter in the inlet of the unit, its size and cleanness.
7.2 First-Startup
• Open the electrical compartment door of the unit using the key provided.
• Check whether all power switches and control-circuit fuses in the electrical section of the unit
are switched OFF.
• Retighten all screw connections in the electric cabinet.
• Verify the smooth function of the contactors.
