WPA180
WPA200
WPA160
WPA140
WPA120
WPA110
WPA100
WPA090
WPA080
WPA070
WPA060
WPA060
WPA070
WPA080
WPA090
WPA100
WPA110
37 © STULZ S.p.A. – all rights reserved EN/06.2016/i01
WPA EXPLORER ORIGINAL INSTRUCTIONS
Water flow [m³/h]
Pressione (kPa)
Water flow [m³/h]
Pressione (kPa)
Pressure drop on the evaporator
Free cooling: net residual head
