ELECTROTECHNICAL INFORMATION ENS 14-18
Electrotechnical Information ENS 14-18
Internal Wiring
4.6
Legend::
CH Relay board
LWU Varistor
SV Solenoid valve
FS1 Float switch for water supply
FS2 Float switch for low water level
TP Thermal protector
NB1..n Ultrasonic nebulization module
WS Water sensor
