ULTRASONIC
8
Copyright STULZ GmbH 02/1997
Unit assembly ENS 14-18
TECHNICAL DATA ENS SERIES
Dimensions L, P refer to page 5 "Dimensions"
Legend:
1 Water supply module l 7 Water supply line*
2 Mist collector 8 Safety overflow
3 Metal plug 9 Water drain
4 Cable 10 Installation base
5 Metal plug 11 Check valve*
6 Cable
*
to be supplied by customers
