PAGE 4 STUV 6 | SPECIFICATIONS & MANUFACTURER INSTALLATION GUIDE
^
OVERVIEW
THE DEVICE
1
Stove
2
Support casing
CONNECTION TO THE COMBUSTION SMOKE OUTLET PIPE
3
Smoke outlet connection piece (vertical or 45º angle)
FINISH
4
Decorative frames
OPTIONS
5
Stand
6
Nozzle Ø100mm for external air inlet from the bottom
7
Rear external air connection kit Ø100mm
1
5
6
7
3
2
4
