Planning Information
Integrated Model 736TC(I)
Dimensions in parentheses are in
millimeters unless otherwise specified.
10
PANEL CONSIDERATIONS
The illustrations below provide panel
width dimensions for installation of a
36" (914) wide tall unit and for
installing two 36" (914) wide tall units
side by side.
I
MPORTANT NOTE:
D
imensions are
based on a
1
/8" (3) reveal. A reveal of
up to
1
/4" (6) is possible, but panel
dimensions need to be adjusted
accordingly.
35
3
4
(
908)
3
4
(19)
P
ANEL
APPLIANCE
DOOR WIDTH
SUB-ZERO
UNIT
T
O BACK
OF UNIT
34
7
8
(
886)
3
6
(914)
24
(610)
C
ABINETRY
OR SIDE
PANEL
25
(635)
C
ABINETRY
OR SIDE
PANEL
25
(635)
1
8
(3)
REVEAL
min
*
1
8
(3)
REVEAL
min
*
*SUBTRACT PANEL WIDTH FROM CABINETRY OPENING TO DETERMINE ACTUAL WIDTH OF REVEAL
C
3
4
(19)
PANEL
3
4
(19)
PANEL
DOOR
SUB-ZERO
UNIT
DOOR
SUB-ZERO
UNIT
72
(1829)
TO BACK
OF UNIT
24
(610)
1
8
(3)
REVEAL
min
*
1
8
(3)
REVEAL
min
*
1
8
(3)
REVEAL
min
*
*SUBTRACT PANEL WIDTH FROM CABINETRY OPENING TO DETERMINE ACTUAL WIDTH OF REVEAL
*
CABINETRY
OR SIDE
PANEL
25
(635)
CABINETRY
OR SIDE
PANEL
25
(635)
35
13
16
(910)
35
13
16
(910)
Panel width dimensions for
installation of a 36" (914) wide
tall unit.
Panel width dimensions for
installation of two 36" (914)
wide tall units side by side.
When
3
/4" (19) or thicker panels are used and a reveal
less than
1
/4" (6) is maintained, the door panels may
cause damage to the Sub-Zero unit when the door is
open at the maximum 105˚ door stop. You should use
the built-in 90˚ door stop to prevent damage.
