FRAMED CABINETRY
I
MPORTANT NOTE:
T
he depth of each Integrated
unit is 24" (610) from the front of the unit to its
back. Your design may necessitate moving the unit
back, or cabinets forward to achieve a flush fit.
1
8
3
4
MIN.
(3)
PANEL
SIDE MOLDING AND
INSTALLATION HARDWARE
PROVIDED BY SUB-ZERO
LINE OF INTERFERENCE*
AT MAXIMUM DOOR OPENING
MOUNTING BRACKET SCREW
(19)
FLUSH
FURNITURE
FINISH
LINE OF INTERFERENCE*
TO BACK
OF UNIT
24
(610)
SUB-ZERO DOOR
34
7
8
(886)
APPLIANCE DOOR WIDTH
REVEAL
T
Door closed – full scale (top view)
105˚ maximum door opening –
1
/4 scale (top view)
*If the panel is thicker than
3
/4" (19), it is recommended that you
utilize the built-in 90˚ door stop to prevent damage to the panel
and face frame.
Planning Information
Integrated Model 736TC(I)
Dimensions in parentheses are in
millimeters unless otherwise specified.
14
24
(610)
LINE OF INTERFERENCE*
SUB-ZERO
DOOR
TO BACK
OF UNIT
To Next Page
