DOOR MOUNTING
DETAIL
DRAWER MOUNTING
DETAIL
TOP OF
ROUGH
OPENING
77
13
/16"*
(1976)
34
1
/2"*
(876)
3
/8"
(10)
13
1
/4"
(337)
1
/2"
(13)
10
1
/4"
(260)
20
3
/8"
(518)
14"(356)
1
5
/16"
(33)
9
3
/4"
(248)
4"
(102)
80"*
(2032)
36"
(914)
24"
(610)
FRONT VIEW
SIDE VIEW
(UNIT DIMENSION) (UNIT DIMENSION)
*
1
/2" (13)
+
_
ADJUSTMENT IN LEVELING LEGS
105˚
90˚
90˚ DOOR OPENING
DOOR/DRAWER
CLOSED
MAXIMUM DOOR OPENING
DOOR/DRAWER
CLOSED
19
1
/2"*
(495)34
1
/2"*
(876)
24"
(610)
34
7
/8" (886)
7"*
(178)
*
DOOR/DRAWER PANEL THICKNESS NOT INCLUDED – DIMENSION WILL VARY WITH INSTALLATION
TOP VIEW
Planning Information
Integrated Model 736TC(I)
2
Dimensions in parentheses are in
millimeters unless otherwise specified.
OVERALL DIMENSIONS
FEATURES
Tall 36" (914) wide combination unit with
upper cabinet refrigerator and freezer storage
drawers
Model 736TCI has automatic ice maker
Integrated design for "point-of-use" refriger-
ation anywhere in the home
Dual refrigeration system with two distinct
temperature zones ensures the freshest food
a
nd energy efficiency
Electronic digital controls are up front and
easy to use
Flat to the ceiling bright lighting in cabinet
and drawers
Door alarm will let you know with an audible
beeping if a door or drawer is left open
Adjustable, spill-proof glass shelves
Crisper with dividers is large and deep, with
smooth sides for easy cleaning
The exclusive dual-action hinge has a built-in
90˚ door stop
Meets strict Department of Energy require-
ments
UL approved for US and Canada
Two, five and twelve year residential
warranty – exclusions apply; warranty
information can be found on our website,
subzer
o.com
Dimensions ma
y vary by ±
1
/8" (3).
