Framed Panels 16
Optional Panel Grille. A louvered grille, providing an
8
4" (2134) overall unit height, is standard on framed
applications. You may choose to use Sub-Zero’s optional
panel grille for your application. The panel grilles can be
used with all built-in models and are available for 83"
(2108), 84" (2134) and 88" (2235) overall unit heights.
Grille panel dimensions listed are for a standard 84"
(2134) overall height of the unit. For an 83" (2108) overall
height, subtract 1" (25) from grille panel height dimen-
sions. For an 88" (2235) overall height, add 4" (102) to
height dimensions.
Optional panel grille.
Optional Grille Panel W H
30" (762) Models 29
3
/4" (756) 8
15
/16" (227)
36" (914) Models 35
3
/4" (908) 8
15
/16" (227)
42" (1067) Models 41
3
/4" (1060) 8
15
/16" (227)
48" (1219) Models 47
3
/4" (1213) 8
15
/16" (227)
Grille Panel Requirements
MAX WEIGHT
Grille Panel 13 lbs (6 kg)
MIN PANEL THICKNESS
Grille Panel
1
/4" (6)
Framed
