Sub-Zero BI-36U Design Guide

Opening Widths A B
Two 30" (762) Models 59
3
/4" (1518) 62
1
/4" (1581)
Two 36" (914) Models 71
3
/4" (1822) 74
1
/4" (1886)
IMPORTANT NOTE: Dimensions assume a
3
/4" (19) panel
thickness. A dual installation kit will be required for this
installation.
Dual Installations 33
Dual Flush Inset Installation Opening Dimensions
24" (
610)
DEPTH
TO CLEAT
26
3
/16"
(665)
FLUSH
INSET
DEPTH
FRONT VIEW
TOP VIEW
2
3
/16"
(56)
A
WIDTH TO CLEAT
B
FLUSH INSET WIDTH
1
1
/4"
(32)
1
1
/4"
(32)
SIDE VIEW
84"
(2134)
FLUSH
INSET
HEIGHT
1
/4"
(6)
24" (610)
DEPTH TO CLEAT
26
3
/16" (665)
FLUSH INSET DEPTH
2
3
/16"
(56)
83
3
/4"
(2127)
HEIGHT
TO CLEAT
83" min
(2108)
CLEAT
OUTLINE OF
TWO UNITS WITH
3
/4" (19) PANEL
DETAIL A
DETAIL B
1
1
/4"
(32)
CLEAT
Detail A
Detail B
1
1
/ 4 "
(32)
24" (610)
OPENING
DEPTH
TO CLEAT
CLEAT
TOP VIEW
26
3
/ 16 "
(665)
FLUSH
INSET
DEPTH
2
3
/ 16 " (56)
3" (76)
typical
24" (610)
OPENING
DEPTH TO
CLEAT
1
1
/ 4 "
(32)
2
3
/ 16 " (56)
CLEAT
SHADED
AREA
MUST BE
FINISHED
3" typical
(76)
4" (102)
Dual Installations
