Sub-Zero BI-36U Design Guide

MAIN FRAME
23
7
/8" (606)
TO REAR OF UNIT
OVERLAY PANEL
3
/4" (19) THICK
(TYPICAL)
APPROX THICKNESS
OF WRAPPED STAINLESS
STEEL DOOR
DOOR CLOSED
DOOR OPEN 90˚
SUB-ZERO UNIT
1
/
4 " (6)
PA N
EL
OVERALL WIDTH
OF UNIT
TOP VIEW
1
1
/
4
"
(32)
1
1
/
2
"
(38)
1
3
/
4
"
(44)
0"
(0)
1"
(25)
2"
(51)
2
1
/
4
"
(57)
2
1
/
2
"
(63)
2
3
/
4
"
(70)
3"
(76)
3
1
/
4
"
(83)
3
1
/
2
"
(89)
1
/
4
"
(6)
1
/
2
"
(13)
3
/
4
"
(19)
1
1
/
4
"
(32) PANEL
3
/
4
"
(19) PANEL
1"
(25) PANEL
This full-scale template
shows what considerations
you need to make for
overlay panel applications
and how they may interact
with adjacent cabinets and
countertops.
Overlay Panel Application—90° Door Opening 39
Full-Scale Templates
subzerotrade.com

Sub-Zero BI-36U Specifications

General

Energy Star Certified	Yes
Ice Maker	Yes
Door Style	French Door
Width	36 inches
Height	84 inches
Depth	24 inches
Lighting	LED
Product Type	Built-In Refrigerator
