Built-In Refrigeration 12
Framed Application
IMPORTANT NOTE: The framed application is not a
separate model. This is an overlay unit in a framed appli-
cation.
The framed panel design option is available for all built-in
overlay models. You must specify panels, full-length
handles and a framed grille insert to achieve the traditional
framed look. For exact door panel dimensions refer to
framed panel specifications on the following pages. Also
refer to the full-scale templates at the end of this section
for additional panel and handle considerations.
Optional extended full-length handles that provide addi-
tional finger clearance for raised panels are available
through your authorized Sub-Zero dealer.
Framed Panel Requirements
MAX WEIGHT PER PANEL
BI-36R, BI-36RG and BI-36F 75 lbs (34 kg)
All Other Framed Panels 50 lbs (23 kg)
MIN PANEL THICKNESS
All Framed Panels
1
/4" (6)
Custom cabinetry panels slide into the door to blend into the
kitchen design. Shown with full-length handle and louvered
grille option for the traditional Sub-Zero look.
