Built-In Refrigeration 14
Models BI-30U and BI-30UG
REFRIGERATOR W H
Door Panel 29
3
/4" (756) 49
15
/16" (1268)
FREEZER W H
Drawer Panel 29
3
/4" (756) 18
11
/16" (475)
BI-30UG W H
Window Cut-Out 19
1
/2" (495) 39
11
/16" (1008)
A
Cut-Out Location 5
3
/16" (132)
Models BI-36U and BI-36UG
REFRIGERATOR W H
Door Panel 35
3
/4" (908) 49
15
/16" (1268)
FREEZER W H
Drawer Panel 35
3
/4" (908) 18
11
/16" (475)
BI-36UG W H
Window Cut-Out 25
1
/2" (648) 39
11
/16" (1008)
A
Cut-Out Location 5
3
/16" (132)
Models BI-36R, BI-36RG and BI-36F
REFRIGERATOR/FREEZER W H
Door Panel 35
3
/4" (908) 69
9
/16" (1767)
BI-36RG W H
Window Cut-Out 25
1
/2" (648) 54
1
/16" (1373)
AB
Cut-Out Location 5
3
/16" (132) 10
5
/16" (262)
Framed Panels
BI-36R / BI-36F BI-36RG BI-30U / BI-36U BI-30UG / BI-36UG
H
W
H
H
W
Model BI-36UFD
REFRIGERATOR (2 PANELS) W H
Door Panels 17
5
/8" (448) 49
15
/16" (1268)
FREEZER W H
Drawer Panel 35
3
/4" (908) 18
11
/16" (475)
H
W
AA
A
B
H
H
W
AA
A
A
H
H
W
W W
BI-36UFD
