Built-In Refrigeration 39
subzero.com/specs
1
/4" (6) BACKER PANEL
DOOR
DEPTH OF TUBULAR
AND PRO HANDLES
1"
(25)
3"
(76)
1
1
/4" (32) PANEL
1" (25) PANEL
3
/4" (19) PANEL
2"
(51)
.10" (3) SPACER PANEL
Overlay Panel Thickness
FULL-SCALE TEMPLATE
Overlay and flush inset panels must be a minimum of
5
/8"
(16) thick to support mounting the handle. Panel thickness
does not include backer and spacer panel. Mount handle
close to the opening edge of the door.
PANEL THICKNESS
OVERLAY AND FLUSH INSET APPLICATIONS
