Wine Storage 82
Wine Shelf Wood Facing
FULL-SCALE TEMPLATE
For each model, the wine storage shelves have a natural
cherrywood facing. You can replace these strips with
wood more complementary to your design and surround-
ing cabinetry. Refer to the full-scale template below.
To remove the cherry strips, take the shelves out and
remove the screws. Reverse the procedure to affix the
new wood facing.
IMPORTANT NOTE: If you choose to stain or seal the
wood facing, be aware that some of these substances are
hazardous and will damage stored wine.
Dimension A
315W 10
15
/16" (278)
424G and 424FSG 19
1
/2" (495)
427G and 427RG 20
15
/15" (532)
WS-30 24
9
/16" (624)
Dimensions will vary for model 315W. Refer to specifications
on our website, subzero.com.
A (WIDTH)
Maximum Thickness
FRONT VIEW
SIDE VIEW
1
1
/2" (38)
5
/8"
(16)
7
/64"
(3)
5
/64"
(2)
23
/64"
(9)
9
/16" (14)
27
/32"
(21)
WINE SHELF WOOD FACING
WINE STORAGE MODELS
