IMPREZA U.S.A. (E)
10
Maintenance and service
10-55
– CONTINUED –
2. Look at the horizontal beam angle gauge. The center mark (the red
line on the inner scale) should not deviate from red line on the outer case
by more than two segments on either side of the gauge.
If the beam angle gauge deviates from the acceptable range, take the
vehicle to your SUBARU dealer for adjustment of the headlight aim.
Replacing bulbs
J Headlight
CAUTION
Halogen headlight bulbs become very hot while in use. If you
touch the bulb surface with bare hands or greasy gloves, finger
prints or grease on the bulb surface develop into hot spots, caus-
ing the bulb to break. If there are finger prints or grease on the
bulb surface, wipe them away with a soft cloth moistened with al-
cohol.
OM-H0261OM-H0243
Retainer spring
Rubber cover
Electrical
connector
1. Disconnect the electrical connector, then remove the rubber cover.
2. Remove the retainer spring.
3. Replace the bulb, then set the retainer spring securely.
4. Install the rubber cover with the top mark facing up, then reconnect
the electrical connector.
To Next Page
