FORESTER U.S.A. (E)
4-12
HS0256HS0255
Filter cover
Screws
New filter
Plastic tab
Rubber seal
Cooling unit
3. Insert a new filter with the plastic tab facing forward.
4. Install the rubber seal on the duct opening.
CAUTION
Make certain that the rubber seal is evenly seated on the duct
opening.
5. Install the filter cover and secure with two (2) screws.
Caution label
HS0257
Center pillar
Change label
6. Fill out information on the small label supplied with the filter kit.
7. Attach the small label on the lower part of the center pillar.
