FORESTER U.S.A. (E)
11-2
Specifications
These specifications are subject to change without notice.
J Dimensions
Overall length 175.2 in. (4,450 mm)
Overall width 68.3 in. (1,735 mm)
Overall height 62.8 in. (1,595 mm)
Ground clearance 7.5 in. (190 mm)
Front tread 58.1 in. (1,475 mm)
Rear tread 57.1 in. (1,450 mm)
Wheelbase 99.4 in. (2,525 mm)
J Engine
Engine model EJ251
Engine type Horizontally opposed, liquid cooled
4 cylinder, 4 stroke gasoline engine
Engine displacement 149.9 cu in. (2,457 cc)
Bore 3.92 in. (99.5 mm)
Stroke 3.11 in. (79.0 mm)
Compression ratio 10.0 : 1
Firing order 1 - 3 - 2 - 4
J Electrical system
Battery
Type MT: 55D23L, AT: 75D23L
Reserve capacity MT: 99 min., AT: 118 min.
Cold cranking ampere MT: 356 amp., AT: 520 amp.
Alternator 12V - 75A
Spark plugs RC10YC4 (Champion),
RC8YC4 (Champion),
BKR6E-11 (NGK),
K20PR-U11 (NIPPONDENSO)
Spark plug gap 0.039 to 0.043 in. (1.0 to 1.1 mm)
