Legacy U.S.A..(ENG.)A2290BE–A
5-8
Type A and B audio set (if equipped)
Type A: Without weather band
Type B: With weather band
The audio set will operate only when the ignition switch is in the “ACC” or
“ON” position.
Radio operation
HB5041BC
1 Power switch/Volume, Tone,
Balance, Fader control dial
2 AUDIO button
3 BAND button
4 Tuning buttons
5 Preset buttons
6 SCAN button
B Power switch and volume/bass/treble/fader/balance control
n Power switch and volume control (PWR/VOL)
The dial
1 is used for both power (ON/OFF) and volume control. The
radio is turned ON and OFF by pushing the dial and the volume is
controlled by turning the dial.
