Legacy U.S.A..(ENG.)A2290BE–A
5-50
McIntosh audio set (if equipped)
The audio set will operate only when the ignition switch is in the “ACC” or
“ON” positions.
CAUTION
The power amplifier for this audio set is mounted under the front
passenger’s seat. The amplifier will become hot if the audio con-
tinues to operate.
Never touch the amplifier. Doing so could cause burns.
Radio operation
HB5053BB
1 POWER ON/OFF/BRIGHT
button
2 FM/AM selection button
3 Tuning/FF⋅FB dial
4 Weather band button
5 Preset buttons
6 Treble sound control knob
7 Volume and fader/balance
control dial
8 Bass sound control knob
To Next Page
