– 8 –
Step Parts to remove Remarks and procedures Fasteners
16
Breather Remove breather cover, breather plate, and
gasket from crankcase.
M6 x 12 : 2 pcs.
10 mm box spanner
17
Main bearing cover
Be careful not to damage the oil seal.
Use a soft hammer and evenly tap around
outer surface of cover.
M6 x 28 : 8 pcs.
soft hammer
10 mm box spanner
MAIN BEARING
COVER CP
STEP 16
STEP 17
GASKET
GASKET
BREATHER PLATE
BREATHER COVER
M6 x 28 FLANGE BOLT : 8 pcs.
M6 x 12 FLANGE BOLT : 2 pcs.
P.T.O. shaft side
