– 9 –
Step Parts to remove Remarks and procedures Fasteners
18
Camshaft and tappets Lay carnkcase on the flywheel side push tappets
up into the block and remove camshaft.
Be careful not to damage camshaft and tappets.
CAMSHAFT
TAPPET
STEP 18
CAMSHAFT
P.T.O. shaft side
