– 33 –
M8 x 16 mm bolt and washer : 2 pcs. (crankcase boss)
M6 x 16 mm bolt and washer : 2 pcs. (exhaust port)
2-3-19 BLOWER HOUSING AND RECOIL STARTER
(1) Attach blower housing to crankcase. Tighten four flange bolts.
M8 x 16 mm flange bolt : 3 pcs.
M8 x 50 mm flange bolt : 1 pc.
2-3-20 CYLINDER BAFFLE AND MUFFLER (step 2; finally fixing)
Finally tighten bolts and nuts for cylinder baffle and muffler securely.
M6 x 8 mm flange bolt : 1 pc. (cylinder buffle) M8 nut : 1 pc. (cylinder buffle)
(2) Install recoil starter to blower housing.
M6 x 8 mm flange bolt : 3 pcs.
Note :
Be careful of pulling direction of starter rope.
Tightening torque
9 - 11 N•m
(90 - 110 kgf•cm)
(6.5 - 8.0 ft•lb.)
Tightening torque
4 - 6 N•m
(40 - 60 kgf•cm)
(2.8 - 4.3 ft•lb.)
Tightening torque
17 - 19 N•m
(170 - 190 kgf•cm)
(12.3 - 13.7 ft•lb.)
Tightening torque
17 - 19 N•m
(170 - 190 kgf•cm)
(12.3 - 13.7 ft•lb.)
Tightening torque
8.5 - 10.5 N•m
(85 - 105 kgf•cm)
(6.1 - 7.5 ft•lb.)
