- 6 -
Step Parts to remove Remarks and procedures Parts Fasteners
10
Throttle body (1) Disconnect the two connectors from ECU under the
throttle body.
(2) Disconnect the two connectors from the two injectors
on the throttle body.
(3) Remove the nuts, adapter and throttle body from the
intake manifold.
M6 Flange nut : 4pcs.
STEP 10
CONNECTER
(ECU)
M6 FLANGE NUT
GOVERNOR LEVER
CONNECTER
(INJECTOR)
CONNECTER
(INJECTOR)
CLEANER
ADAPTER
