4-17 SECTIONAL VIEW OF THE ENGINE
Cross sectional view – across the shaft
OIL PRESSURE SWITCH
PISTON
PISTON RING
SUCTION PIPE
PLUG
CYLINDER HEAD
PISTON PIN
OIL PUMP
RECOIL STARTER
FLYWHEEL
MAIN BEARING COVER
ADAPTER
CRANKSHAFT
CRANKCASE
SPARK PLUG
P.T.O. SHAFT
IGNITION COIL
SER No. (Stamping)
