Subaru ER12 - 15-3 Tightening Torque; 15-4 Air Gap and Clearance

- 74 -
15-3 TIGHTENING TORQUE
Description
Tightening Torque
N
・
m kgf
・
cm ft
・
lb
Oil drain bolt 11 - 13 110 - 130 80 - 94
Connectiong rod cap bolts 6 - 8 60 - 80 43 - 58
Cylinder head bolts 20 - 24 200 - 240 145 - 174
Suction pipe bolts 6 - 8 60 - 80 43 - 58
Switch (oil pressuer) 8 - 10 80 - 100 58 - 72
Plug UN (oil filter) 08 - 12 8 - 12 058 - 087
Main bearing cover bolts 24 - 26 240 - 260 174 - 188
Oil pump cover bolts 7 - 9 70 - 90 51 - 65
Rocker arm adjust screw nuts 5 - 7 50 - 70 36 - 51
Rocker cover bolts 5 - 7 50 - 70 36 - 51
Spark plug
New 10 - 12 100 - 120 72 - 87
Re-use 20 - 23 200 - 230 145 - 166
Breather cover bolts 7 - 9 70 - 90 51 - 65
Flywheel nut 60 - 70 600 - 700 434 - 506
Ignition coil bolts 7 - 9 70 - 90 51 - 65
Pivot bolt (speed control) 7 - 9 70 - 90 51 - 65
Air cleaner
Flowt type 7 - 9 70 - 90 51 - 65
Diaphragm type 4 - 5 40 - 50 29 - 36
Muffler nuts 19 - 21 190 - 210 137 - 152
Recoil starter bolts 5 - 7 50 - 70 36 - 51
15-4 AIR GAP AND CLEARANCE
ITEM
Clearance
mm in
Valve clearance (Intake
,
Exhaust) 011 - 016 00043 - 00063
Air gap (Ignition coil and flywheel) 03 - 05 0012 - 0020
Electrode gap (Spark plug) 06 - 07 0024 - 0028
