北米Model "A2600BE-B" EDITED: 2020/ 10/ 1
& Power Window Operation
s02ah07
! Power window switches
s02ah0701
. Driver’s side power window switches:
1) For front left window (with one-touch auto
up and down feature)
2) For front right window (with one-touch
auto up and down feature)
3) For rear left window (with one-touch auto
up and down feature (if equipped))
4) For rear right window (with one-touch
auto up and down feature (if equipped))
5) Lock switch
All door windows can be controlled by the
power window switch cluster on the driver
side door.
The switch illuminates when operated.
. Passenger’s side power window
switches:
Each passenger’s window can be con-
trolled by the power window switch located
on the door.
The switch illuminates when operated.
! Operating the window
s02ah0702
With one-touch auto up and down feature
1) Automatically close*
2) Close
3) Open
4) Automatically open*
*: To stop the window halfway, operate the
switch to the opposite side.
Windows
146
