北米Model "A2600BE-B" EDITED: 2020/ 10/ 1
CAUTION
Do not leave the cover dangling.
Make sure the stoppers are hooked
on to the cover housing. Otherwise
the cover may be torn and damaged.
! To lift the cover
s06ak0102
CAUTION
Do not drive with the cover lifted up.
Doing so could obstruct the rear-
ward view.
1. Push down the handle in the center to
lift the cover up.
The stoppers will slide up the grooves and
stop at the top.
2. To lower the lifted cover, hold the cover
by the handle and pull it back into to the
catches.
& To Remove the Cover Hous-
ing
s06ak02
1. Slowly rewind the cover completely.
Then tilt the cover up by the handle to hook
the stoppers.
2. Push the front cover rod on the right
side against the cargo area trim to shorten
the front cover rod.
3. Remove the front cover and place it on
the cover housing.
– CONTINUED –
Lifting Cargo Cover (Outback – If Equipped)
317
6
Interior Equipment
To Next Page
