Subaru Outback 2021 - Page 322

(318,1)
北米Model "A2600BE-B" EDITED: 2020/ 10/ 1
! To extend the cover
s06ak0101
A Stopper
1) Tilt up
2) Pull out
1. Hold the cover by the handle in the
center, tilt it up and pull it out to free the
stoppers.
2. Pull out the cover by the handle in the
center to extend it. Then insert the
stoppers into the catches as shown.
! To rewind the cover
s06ak0103
1. Hold the cover by the handle in the
center and pull it toward you, then slightly
lower it to free the stoppers in the catches.
A) Stopper
1) Rewind
2) Tilt up
2. Slowly rewind the cover completely.
Then tilt the cover up by the handle to hook
the stoppers.
Lifting Cargo Cover (Outback – If Equipped)
316
