北米Model "A2600BE-B" EDITED: 2020/ 10/ 1
4-1. Ventilator Control
s04af
& Center Ventilators
s04af01
Move the tabs to adjust the flow direction.
To close the ventilator, move the tab all the
way down.
& Side Ventilators
s04af02
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the side grille
open/close wheel upward to the “
”
position.
To close it, turn the wheel downward to the
“
” position.
& Rear Ventilators (If Equipped)
s04af04
1) Open
2) Close
Move the tab to adjust the flow direction.
To open the ventilator, turn the rear grille
open/close wheel upward to the “
”
position.
To close it, turn the wheel downward to the
“
” position.
Ventilator Control
278
