WARNING
Do not connect two or more lower
hooks onto the same anchorage
(bar).
Two lower anchorages (bars) are provided
for installing a child restraint system on the
rear seat window-side seating positions.
Lower anchorages (bars) for window-side
seating positions may be used for a seat in
the center seating position if a child
restraint system manufacturer’s instruc-
tions permit and specify using anchors as
far apart as those in this vehicle. Each
lower anchorage is located where the seat
cushion meets the seatback.
! Tether anchorages
s01ag070102
Legacy
1) For right seat
2) For center seat
3) For left seat
Outback
1) For left seat
2) For center seat
3) For right seat
The tether anchorages (upper an-
chorages) are provided at the locations
shown in the above illustration. For details,
– CONTINUED –
Child Restraint Systems
71
1
Seat, Seatbelt and SRS Airbags
To Next Page
