Subzero Classic Series User Manual

subzero.com | 5
Opening Dimensions
FLUSH INSET INSTALLATION
Dimensions assume a ⁄"
(19) panel thickness. If two units
are installed side by side, refer to page 7.
FLUSH INSET WIDTH W
Model CL3050W 32" (813)
84"
(2134)
FLUSH
INSET
HEIGHT
1
/4"
(6)
26
3
/16"
(665)
FLUSH
INSET
DEPTH
2
3
/
16
"
(56)
FRONT VIEW
SIDE VIE
W
TOP VIEW
1
1
/4"
(32)
W
FLUSH INSET WIDTH
FINISHED
CLEATS
NOTE: 3
1
/2" (89) finished returns and shaded areas will be visible and should be finished to match cabinetry.
Shaded line represents profile of unit with
3
/4" (19) panel.
5
11
/16"
(145)
FINISHED
RETURN
FILLER
FRAMED
CABINETRY
W
CLEAT
3
/4" (19)
TYPICAL
3
1
/2"
(89)
5
11
/
16
"
(145)
FINISHED
RETURN
FRAMELESS
CABINETRY
W
3
1
/2"
(89)
CLEAT
3
/
4
"
(19)
TYPICAL
Site Preparation

Subzero Classic Series Specifications

General

Available Widths	24"
Interior Lighting	LED lighting
Temperature Zones	Dual Zone
Energy Efficiency	Energy Star
Finish	Stainless steel
Series	Classic Series
