Sullair FX Series User Manual

FILTERS AND MOISTURE SEPARATORS SECTION 2
26
4” FLG 2500
1/2” 02250194-530 FW-02500-FR-400-AD-SG-FLG (SULL) 02250194-594 E-600-FR (4 pcs) 4
4” FLG 2500
1/2” 02250194-543 FW-02500-FRHT-400-AD-FLG (SULL) 02250194-595 E-600-FRHT (4 pcs) 4
4” FLG 2500
1/2” 02250194-556 FW-02500-H-400-AD-SG-FLG (SULL) 02250194-596 E-600-H (4 pcs) 4
4” FLG 2500
1/2” 02250194-569 FW-02500-HR-400-AD-SG-FLG (SULL) 02250194-597 E-600-HR (4 pcs) 4
6” FLG 3800
1/2” 02250194-583 FW-03800-C-600-FLG (SULL) 02250194-592 E-600-C (6 pcs) 6
6” FLG 3800
1/2” 02250194-516 FW-03800-F-600-AD-SG-FLG (SULL) 02250194-593 E-600-F (6 pcs) 6
6” FLG 3800
1/2” 02250194-531 FW-03800-FR-600-AD-SG-FLG (SULL) 02250194-594 E-600-FR (6 pcs) 6
6” FLG 3800
1/2” 02250194-544 FW-03800-FRHT-600-AD-FLG (SULL) 02250194-595 E-600-FRHT (6 pcs) 6
6” FLG 3800
1/2” 02250194-557 FW-03800-H-600-AD-SG-FLG (SULL) 02250194-596 E-600-H (6 pcs) 6
6” FLG 3800
1/2” 02250194-570 FW-03800-HR-600-AD-SG-FLG (SULL) 02250194-597 E-600-HR (6 pcs) 6
6” FLG 5000
1/2” 02250194-584 FW-05000-C-600-FLG (SULL) 02250194-592 E-600-C (8 pcs) 8
6” FLG 5000
1/2” 02250194-517 FW-05000-F-600-AD-SG-FLG (SULL) 02250194-593 E-600-F (8 pcs) 8
6” FLG 5000
1/2” 02250194-532 FW-05000-FR-600-AD-SG-FLG (SULL) 02250194-594 E-600-FR (8 pcs) 8
6” FLG 5000
1/2” 02250194-545 FW-05000-FRHT-600-AD-FLG (SULL) 02250194-595 E-600-FRHT (8 pcs) 8
6” FLG 5000
1/2” 02250194-558 FW-05000-H-600-AD-SG-FLG (SULL) 02250194-596 E-600-H (8 pcs) 8
6” FLG 5000
1/2” 02250194-571 FW-05000-HR-600-AD-SG-FLG (SULL) 02250194-597 E-600-HR (8 pcs) 8
8” FLG 6500
1/2” 02250194-585 FW-06500-C-800-FLG (SULL) 02250194-592 E-600-C (10 pcs) 10
8” FLG 6500
1/2” 02250194-518 FW-06500-F-800-AD-SG-FLG (SULL) 02250194-593 E-600-F (10 pcs) 10
8” FLG 6500
1/2” 02250194-533 FW-06500-FR-800-AD-SG-FLG (SULL) 02250194-594 E-600-FR (10 pcs) 10
8” FLG 6500
1/2” 02250194-546 FW-06500-FRHT-800-AD-FLG (SULL) 02250194-595 E-600-FRHT (10 pcs) 10
8” FLG 6500
1/2” 02250194-559 FW-06500-H-800-AD-SG-FLG (SULL) 02250194-596 E-600-H (10 pcs) 10
8” FLG 6500
1/2” 02250194-572 FW-06500-HR-800-AD-SG-FLG (SULL) 02250194-597 E-600-HR (10 pcs) 10
8” FLG 8300
1/2” 02250194-586 FW-08300-C-800-FLG (SULL) 02250194-592 E-600-C (14 pcs) 14
8” FLG 8300
1/2” 02250194-519 FW-08300-F-800-AD-SG-FLG (SULL) 02250194-593 E-600-F (14 pcs) 14
8” FLG 8300
1/2” 02250194-534 FW-08300-FR-800-AD-SG-FLG (SULL) 02250194-594 E-600-FR (14 pcs) 14
8” FLG 8300
1/2” 02250194-547 FW-08300-FRHT-800-AD-FLG (SULL) 02250194-595 E-600-FRHT (14 pcs) 14
8” FLG 8300
1/2” 02250194-560 FW-08300-H-800-AD-SG-FLG (SULL) 02250194-596 E-600-H (14 pcs) 14
8” FLG 8300
1/2” 02250194-573 FW-08300-HR-800-AD-SG-FLG (SULL) 02250194-597 E-600-HR (14 pcs) 14
10” FLG 10000
1/2” 02250194-587 FW-10000-C-1000-FLG (SULL) 02250194-592 E-600-C (16 pcs) 16
10” FLG 10000
1/2” 02250194-520 FW-10000-F-1000-AD-SG-FLG (SULL) 02250194-593 E-600-F (16 pcs) 16
10” FLG 10000
1/2” 02250194-535 FW-10000-FR-1000-AD-SG-FLG (SULL) 02250194-594 E-600-FR (16 pcs) 16
10” FLG 10000
1/2” 02250194-548 FW-10000-FRHT-1000-AD-FLG (SULL) 02250194-595 E-600-FRHT (16 pcs) 16
10” FLG 10000
1/2” 02250194-561 FW-10000-H-1000-AD-SG-FLG (SULL) 02250194-596 E-600-H (16 pcs) 16
10” FLG 10000
1/2” 02250194-574 FW-10000-HR-1000-AD-SG-FLG (SULL) 02250194-597 E-600-HR (16 pcs) 16
12” FLG 12400
1/2” 02250194-588 FW-12400-C-1200-FLG (SULL) 02250194-592 E-600-C (18 pcs) 18
12” FLG 12400
1/2” 02250194-521 FW-12400-F-1200-AD-SG-FLG (SULL) 02250194-593 E-600-F (18 pcs) 18
Table 2-4: FW Filters Technical Data and Spare Parts List
In/Out
FLOW
@ 100
psig
DRAIN
PORT
SIZE
SULLAIR
FILTER
PART NO.
FILTER MODEL REFERENCE
SULLAIR
ELEMENT
PART NO.
ELEMENT and QTY
REQUIRED
ELEM
QTY
REQ.
