SECTION 2 FILTERS AND MOISTURE SEPARATORS
25
2.11 FW SERIES—WELDED FILTERS SPECIFICATIONS
Filter, 2 1/2" NPT FRHT 02250194-413 FX-1350-FRHT-250-AD-NPT (SULL) 02250193-585
Filter, 3" NPT FRHT 02250194-414 FX-1350-FRHT-300-AD-NPT (SULL) 02250193-585
Filter, 2 1/2" NPT H 02250193-482 FX-1350-H-250-AD-SG-NPT (SULL) 02250193-597
Filter, 3" NPT H 02250193-483 FX-1350-H-300-AD-SG-NPT (SULL) 02250193-597
Filter, 2 1/2" NPT HR 02250193-507 FX-1350-HR-250-AD-SG-NPT (SULL) 02250193-609
Filter, 3" NPT HR 02250193-508 FX-1350-HR-300-AD-SG-NPT (SULL) 02250193-609
Filter, 2 1/2" NPT C 02250193-532 FX-1350-C-250-NPT (SULL) 02250193-563
Filter, 3" NPT C 02250193-533 FX-1350-C-300-NPT (SULL) 02250193-563
Filter, 2 1/2" NPT U 02250195-233 FX-1350-U-250-AD-SG-NPT (SULL) 02250195-208
Filter, 3" NPT U 02250195-234 FX-1350-U-300-AD-SG-NPT (SULL) 02250195-208
Filter, 3" NPT F 02250195-185 FX-1600-F-300-AD-SG-NPT (SULL) 02250195-593
Filter, 3" NPT FR 02250195-186 FX-1600-FR-300-AD-SG-NPT (SULL) 02250195-194
Filter, 3" NPT FRHT 02250195-187 FX-1600-FRHT-300-AD-NPT (SULL) 02250195-194
Filter, 3" NPT H 02250195-189 FX-1600-H-300-AD-SG-NPT (SULL) 02250195-196
Filter, 3" NPT HR 02250195-190 FX-1600-HR-300-AD-SG-NPT (SULL) 02250195-197
Filter, 3" NPT C 02250195-191 FX-1600-C-300-NPT (SULL) 02250195-192
Filter, 3" NPT U 02250195-235 FX-1600-U-300-AD-SG-NPT (SULL) 02250195-209
Table 2-4: FW Filters Technical Data and Spare Parts List
In/Out
FLOW
@ 100
psig
DRAIN
PORT
SIZE
SULLAIR
FILTER
PART NO.
FILTER MODEL REFERENCE
SULLAIR
ELEMENT
PART NO.
ELEMENT and QTY
REQUIRED
ELEM
QTY
REQ.
3” FLG 1500
1/2” 02250194-580 FW-01500-C-300-FLG (SULL) 02250194-592 E-600-C (2 pcs) 2
3” FLG 1500
1/2” 02250194-513 FW-01500-F-300-AD-SG-FLG (SULL) 02250194-593 E-600-F (2 pcs) 2
3” FLG 1500
1/2” 02250194-528 FW-01500-FR-300-AD-SG-FLG (SULL) 02250194-594 E-600-FR (2 pcs) 2
3” FLG 1500
1/2” 02250194-541 FW-01500-FRHT-300-AD-FLG (SULL) 02250194-595 E-600-FRHT (2 pcs) 2
3” FLG 1500
1/2” 02250194-554 FW-01500-H-300-AD-SG-FLG (SULL) 02250194-596 E-600-H (2 pcs) 2
3” FLG 1500
1/2” 02250194-567 FW-01500-HR-300-AD-SG-FLG (SULL) 02250194-597 E-600-HR (2 pcs) 2
4” FLG 1900
1/2” 02250194-581 FW-01900-C-400-FLG (SULL) 02250194-592 E-600-C (3 pcs) 3
4” FLG 1900
1/2” 02250194-514 FW-01900-F-400-AD-SG-FLG (SULL) 02250194-593 E-600-F (3 pcs) 3
4” FLG 1900
1/2” 02250194-529 FW-01900-FR-400-AD-SG-FLG (SULL) 02250194-594 E-600-FR (3 pcs) 3
4” FLG 1900
1/2” 02250194-542 FW-01900-FRHT-400-AD-FLG (SULL) 02250194-595 E-600-FRHT (3 pcs) 3
4” FLG 1900
1/2” 02250194-555 FW-01900-H-400-AD-SG-FLG (SULL) 02250194-596 E-600-H (3 pcs) 3
4” FLG 1900
1/2” 02250194-568 FW-01900-HR-400-AD-SG-FLG (SULL) 02250194-597 E-600-HR (3 pcs) 3
4” FLG 2500
1/2” 02250194-582 FW-02500-C-400-FLG (SULL) 02250194-592 E-600-C (4 pcs) 4
4” FLG 2500
1/2” 02250194-515 FW-02500-F-400-AD-SG-FLG (SULL) 02250194-593 E-600-F (4 pcs) 4
Table 2-3: FX Filter Series
NPT TYPE
SULLAIR FILTER
PART NO.
MODEL
SULLAIR ELEMENT
PART NO.

Sullair FX Series Specifications
