2.12 FH SERIES—HIGH PRESSURE FILTERS SPECIFICATIONS

Table 2-5: FH Fiilters Technical Data and Spare Parts List

FILTER FILTER

MAX WORKING

PRESSURE

PORT

SIZE

FLOW RATE ELEMENT HOUSING DIMENSIONS IN INCHES (mm)

MODEL NO Part No (bar/psig) NPT m3/h scfm Part Number(s) A B C D

FH-0060-F-025-MD-NPT 02250194-803 50/725 1/4” 100 60 02250194-845 4.46 (113.4) 4.54 (115.4) 1.01 (25.75) 6.1 (155)

FH-0175-F-050-MD-NPT 02250194-804 50/725 1/2” 300 175 02250194-846 4.46 (113.4) 4.54 (115.4) 1.01 (25.75) 6.24 (158.5)

FH-0350-F-075-MD-NPT 02250194-805 50/725 3/4” 600 350 02250194-847 4.3 (109.4) 4.54 (115.4) 1.26 (32.25) 8.14 (207)

FH-0500-F-100-MD-NPT 02250194-806 50/725 1” 850 500 02250194-848 5.23 (133) 5.43 (138) 1.47 (37.35) 9.84 (250)

FH-0700-F-100-MD-NPT 02250194-807 50/725 1” 1200 700 02250194-849 5.23 (133) 5.43 (138) 1.47 (37.35) 12.36 (314)

FH-0950-F-150-MD-NPT 02250194-808 50/725 1 1/2” 1600 950 02250194-850 5.03 (128) 5.43 (138) 1.74 (44.4) 14.48 (368)

FH-1500-F-200-MD-NPT 02250194-809 50/725 2” 2500 1500 02250194-851 5.7 (145) 6.22 (158) 2.02 (51.5) 15.47 (393)

FH-1750-F-250-MD-NPT 02250195-910 50/725 2 1/2” 3000 1750 02250194-915 6.29 (160) 7 (178) 2.26 (57.6) 15.19 (386)

FH-0060-H-025-MD-NPT 02250194-811 50/725 1/4” 100 60 02250194-853 4.46 (113.4) 4.54 (115.4) 1.01 (25.75) 6.1 (155)

FH-0175-H-050-MD-NPT 02250194-812 50/725 1/2” 300 175 02250194-854 4.46 (113.4) 4.54 (115.4) 1.01 (25.75) 6.24 (158.5)

FH-0350-H-075-MD-NPT 02250194-813 50/725 3/4” 600 350 02250194-855 4.3 (109.4) 4.54 (115.4) 1.26 (32.25) 8.14 (207)

FH-0500-H-100-MD-NPT 02250194-814 50/725 1” 850 500 02250194-856 5.23 (133) 5.43 (138) 1.47 (37.35) 9.84 (250)

FH-0700-H-100-MD-NPT 02250194-815 50/725 1” 1200 700 02250194-857 5.23 (133) 5.43 (138) 1.47 (37.35) 12.36 (314)

FH-0950-H-150-MD-NPT 02250194-816 50/725 1 1/2” 1600 950 02250194-858 5.03 (128) 5.43 (138) 1.74 (44.4) 14.48 (368)

FH-1500-H-200-MD-NPT 02250194-817 50/725 2” 2500 1500 02250194-859 5.7 (145) 6.22 (158) 2.02 (51.5) 15.47 (393)

FH-1750-H-250-MD-NPT 02250195-911 50/725 2 1/2” 3000 1750 02250194-916 6.29 (160) 7 (178) 2.26 (57.6) 15.19 (386)

FH-0060-C-025-MD-NPT 02250194-819 50/725 1/4” 100 60 02250194-861 4.46 (113.4) 4.54 (115.4) 1.01 (25.75) 6.1 (155)

FH-0175-C-050-MD-NPT 02250194-820 50/725 1/2” 300 175 02250194-862 4.46 (113.4) 4.54 (115.4) 1.01 (25.75) 6.24 (158.5)

FH-0350-C-075-MD-NPT 02250194-821 50/725 3/4” 600 350 02250194-863 4.3 (109.4) 4.54 (115.4) 1.26 (32.25) 8.14 (207)

FH-0500-C-100-MD-NPT 02250194-822 50/725 1” 850 500 02250194-864 5.23 (133) 5.43 (138) 1.47 (37.35) 9.84 (250)

FH-0700-C-100-MD-NPT 02250194-823 50/725 1” 1200 700 02250194-865 5.23 (133) 5.43 (138) 1.47 (37.35) 12.36 (314)

FH-0950-C-150-MD-NPT 02250194-824 50/725 1 1/2” 1600 950 02250194-866 5.03 (128) 5.43 (138) 1.74 (44.4) 14.48 (368)

FH-1500-C-200-MD-NPT 02250194-825 50/725 2” 2500 1500 02250194-867 5.7 (145) 6.22 (158) 2.02 (51.5) 15.47 (393)

FH-1750-C-250-MD-NPT 02250195-912 50/725 2 1/2” 3000 1750 02250194-868 6.29 (160) 7 (178) 2.26 (57.6) 15.19 (386)
