SECTION 2 FILTERS AND MOISTURE SEPARATORS
29
Table 2-6: FH Filters Specifications
SPECIFICATION
GENERAL
PURPOSE
OIL
REMOVAL
ACTIVATED
CARBON
Grade F H C
Particle Removal (Micron) 1 0,01 0,01
Max. Oil Carryover at 21C (ppm) 0.5 0,01 0,003
Max. Working Temperature (
°F)
176 176 77
Initial Pressure Loss (psig) 1.16 1.45 1.16
Pressure Loss for Element Change (mbar) 10 10 10
Element Color Code Blue Red Metal
Notes:
1. Grade C must not operate in oil saturated conditions.
2. Grade C elements should be replaced periodically to suit the applications but must be changed at least every six months.
3. Grade C will not remove certain gases including carbon monoxide and carbon dioxide. Please refer to works if in doubt.
4. All filters are suitable for use with mineral and synthetic oils.
5. The above housings require only one filter element.
6. Direction of air flow, inside to out, through filter element. Except Grade C.
Table 2-7: FH Filters Series
SULLAIR PART
NUMBER
Description ELEMENT
2nd DESCRIPTION /
PERFORMANCE
NPT
02250194-803
FLR, HP (725PSI) 1/4''-
60CFM - 1 micron
02250194-845
1 MICRON & .5 ppm
Carryover
1/4''
02250194-804
FLR, HP (725PSI) 1/2''-
175CFM - 1 micron
02250194-846
1 MICRON & .5 ppm
Carryover
1/2''
02250194-805
FLR, HP (725PSI) 3/4''-
350CFM - 1 micron
02250194-847
1 MICRON & .5 ppm
Carryover
3/4''
02250194-806
FLR, HP (725PSI) 1''-
500CFM - 1 micron
02250194-848
1 MICRON & .5 ppm
Carryover
1''
02250194-807
FLR, HP (725PSI) 1''-
700CFM - 1 micron
02250194-849
1 MICRON & .5 ppm
Carryover
1''
02250194-808
FLR, HP (725PSI) 1-1/2''-
950CFM - 1 micron
02250194-850
1 MICRON & .5 ppm
Carryover
1-1/2''
02250194-809
FLR, HP (725PSI) 2''-
1500CFM - 1 micron
02250194-851
1 MICRON & .5 ppm
Carryover
2''
02250195-910
FLR, HP (725PSI) 2-1/2''-
1750CFM - 1 micron
02250195-915
1 MICRON & .5 ppm
Carryover
2-1/2"
To Next Page
