Sullair FX Series User Manual

SECTION 2 FILTERS AND MOISTURE SEPARATORS
33
2.13 REPRESENTATIVE FILTER (FX MODEL)
FILTER MODEL PART NUMBER
PORT SIZE
NPT
SCFM
DIMENSION IN INCHES (mm)
O-RING SIZE (mm)
WEIGHT
AB C lbs
FX-0025-025-AD-SG-NPT 02250193-460 1/4” 25 4.01 (102) 8.09 (205.6) 7.22 (183.5) RNG75x2.62 2.6
FX-0025-038-AD-SG-NPT 02250193-461 3/8” 25 4.01 (102) 8.09 (205.6) 7.22 (183.5) RNG75x2.62 2.6
FX-0025-050-AD-SG-NPT 02250193-462 1/2” 25 4.01 (102) 8.09 (205.6) 7.22 (183.5) RNG75x2.62 2.6
FX-0045-038-AD-SG-NPT 02250193-463 3/8” 45 4.01 (102) 9.59 (243.6) 8.72 (221.5) RNG75x2.62 2.9
FX-0045-050-AD-SG-NPT 02250193-464 1/2” 45 4.01 (102) 9.59 (243.6) 8.72 (221.5) RNG75x2.62 2.9
FX-0065-050-AD-SG-NPT 02250193-465 1/2” 65 4.84 (123) 11.35 (288.5) 10.29 (261.5) RNG95x2.62 4
FX-0065-075-AD-SG-NPT 02250193-466 3/4” 65 4.84 (123) 11.35 (288.5) 10.29 (261.5) RNG95x2.62 4
FX-0065-0100-AD-SG-NPT 02250193-467 1” 65 4.84 (123) 11.35 (288.5) 10.29 (261.5) RNG95x2.62 4
FX-0130-075-AD-SG-NPT 02250193-468 3/4” 130 4.84 (123) 15.45 (392.5) 14.38 (365.5) RNG95x2.62 5.8
FX-0130-0100-AD-SG-NPT 02250193-469 1” 130 4.84 (123) 15.45 (392.5) 14.38 (365.5) RNG95x2.62 5.8
FX-0240-100-AD-SG-NPT 02250193-470 1” 240 4.84 (123) 18.85 (479) 17.46 (443.5) RNG95x2.62 6.8
FX-0240-125-AD-SG-NPT 02250193-471 1 1/4” 240 4.84 (123) 18.85 (479) 17.46 (443.5) RNG95x2.62 6.8
FX-0240-150-AD-SG-NPT 02250193-472 1 1/2” 240 4.84 (123) 18.85 (479) 17.46 (443.5) RNG95x2.62 6.8
FX-0350-125-AD-SG-NPT 02250193-473 1 1/4” 350 4.84 (123) 20.62 (524) 19.23 (488.5) RNG95x2.62 7.4
FX-0350-150-AD-SG-NPT 02250193-474 1 1/2” 350 4.84 (123) 20.62 (524) 19.23 (488.5) RNG95x2.62 7.4
FX-0475-125-AD-SG-NPT 02250193-475 1 1/4” 475 6.29 (160) 24.07 (611.5) 22.43 (569.8) RNG125.2x2.62 11.6
FX-0475-150-AD-SG-NPT 02250193-476 1 1/2” 475 6.29 (160) 24.07 (611.5) 22.43 (569.8) RNG125.2x2.62 11.6
FX-0475-200-AD-SG-NPT 02250193-477 2” 475 6.29 (160) 24.07 (611.5) 22.43 (569.8) RNG125.2x2.62 11.6
FX-0700-200-AD-SG-NPT 02250193-478 2” 700 6.29 (160) 26.83 (681.5) 25.18 (639.8) RNG125.2x2.62 12.5
FX-0925-200-AD-SG-NPT 02250193-479 2” 925 7.637 (194) 28.47 (730) 26.45 (672) RNG150.3x3 18.6
FX-0925-250-AD-SG-NPT 02250193-480 2 1/2” 925 7.637 (194) 28.47 (730) 26.45 (672) RNG150.3x3 18.6
FX-0925-300-AD-SG-NPT 02250193-481 3” 925 7.637 (194) 28.47 (730) 26.45 (672) RNG150.3x3 18.6
FX-1350-250-AD-SG-NPT 02250193-482 2 1/2” 1350 7.637 (194) 36.37 (924) 34.13 (867) RNG150.3x3 22.2
FX-1350-300-AD-SG-NPT 02250193-483 3” 1350 7.637 (194) 36.37 (924) 34.13 (867) RNG150.3x3 22.2
FX-1600-300-AD-SG-NPT 02250195-189 3” 1350 7.637 (194) 42.04 (1068) 39.8 (1011) RNG150.3x3 24.5
NOTE DESCRIPTION DESIGN PARAMETERS:
1 ALL DIMENSIONS ARE INCHES
DESIGN CODE
DESIGN PRESSURE
DESIGN TEMPERATURE
97/23/CE PRESSURE EQUIPMENT DIRECTIVE
290 psig
212°F
E 2 FILTER HEAD DIE CAST ALUMNIUM
CORROSION PROTECTION:
ANODISED SURFACE TREATMENT FOR INTERNAL SURFACES.
POWDER PAINT COATING FOR EXTERNAL SURFACES.
NOTES:
INDICATED WEIGHTS ARE NET WEIGHTS.
F 3 FILTER BOWL EXTRUDED ALUMINUM
G4
PAINT CODE WILL BE RAL6021 AND PAINT
THICKNESS SHALL BE 80-90u
