SECTION 2 FILTERS AND MOISTURE SEPARATORS
35
2.14 REPRESENTATIVE FILTER (FW MODEL)
FILTER MODEL PART NUMBER
INLET/OUTLET
PORT SIZE
FLOW SCFM DIMENSION IN INCHES
DRAIN PORT SIZE
NPT/BSPT
ELEMENT
QTY
ABCD
FW-01500-F-300-AD-SG-FLG 02250194-513 3” FLG 1500 18.0 46.0 6.0 30.0 1/2” NPT 02250194-593 2
FW-01900-F-400-AD-SG-FLG 02250194-514 4” FLG 1900 18.0 46.0 6.0 30.0 1/2” NPT 02250194-593 3
FW-02500-F-400-AD-SG-FLG 02250194-515 4” FLG 2500 21.0 46.0 6.0 30.0 1/2” NPT 02250194-593 4
FW-03800-F-600-AD-SG-FLG 02250194-516 6” FLG 3800 23.0 50.0 8.7 31.5 1/2” NPT 02250194-593 6
FW-05000-F-600-AD-SG-FLG 02250194-517 6” FLG 5000 23.0 51.0 10.0 31.7 1/2” NPT 02250194-593 8
FW-06500-F-800-AD-SG-FLG 02250194-518 8” FLG 6500 29.0 53.4 10.0 32.8 1/2” NPT 02250194-593 10
FW-08300-F-800-AD-SG-FLG 02250194-519 8" FLG 8300 30.0 55.0 10.0 32.9 1/2” NPT 02250194-593 14
FW-10000-F-1000-AD-SG-FLG 02250194-520 10" FLG 10000 32.0 58.0 12.8 34.0 1/2” NPT 02250194-593 16
FW-12400-F-1200-AD-SG-FLG 02250194-521 12" FLG 12400 32.0 60.0 14.6 35.0 1/2” NPT 02250194-593 18
FW-15000-F-1400-AD-SG-FLG 02250194-522 14" FLG 15000 40.0 63.0 14.3 36.0 1/2” NPT 02250194-593 24
FW-17700-F-1400-AD-SG-FLG 02250194-523 14" FLG 17700 40.0 63.0 14.3 36.0 1/2” NPT 02250194-593 28
FW-01500-FR-300-AD-SG-FLG 02250194-528 3” FLG 1500 18.0 46.0 6.0 30.0 1/2” NPT 02250194-594 2
FW-01900-FR-400-AD-SG-FLG 02250194-529 4” FLG 1900 18.0 46.0 6.0 30.0 1/2” NPT 02250194-594 3
FW-02500-FR-400-AD-SG-FLG 02250194-530 4” FLG 2500 21.0 46.0 6.0 30.0 1/2” NPT 02250194-594 4
FW-03800-FR-600-AD-SG-FLG 02250194-531 6” FLG 3800 23.0 50.0 8.7 31.5 1/2” NPT 02250194-594 6
FW-05000-FR-600-AD-SG-FLG 02250194-532 6” FLG 5000 23.0 51.0 10.0 31.7 1/2” NPT 02250194-594 8
FW-06500-FR-800-AD-SG-FLG 02250194-533 8” FLG 6500 29.0 53.4 10.0 32.8 1/2” NPT 02250194-594 10
FW-08300-FR-800-AD-SG-FLG 02250194-534 8" FLG 8300 30.0 55.0 10.0 32.9 1/2” NPT 02250194-594 14
FW-10000-FR-1000-AD-SG-FLG 02250194-535 10" FLG 10000 32.0 58.0 12.8 34.0 1/2” NPT 02250194-594 16
FW-12400-FR-1200-AD-SG-FLG 02250194-536 12" FLG 12400 32.0 60.0 14.6 35.0 1/2” NPT 02250194-594 18
FW-15000-FR-1400-AD-SG-FLG 02250194-537 14" FLG 15000 40.0 63.0 14.3 36.0 1/2” NPT 02250194-594 24
FW-17700-FR-1400-AD-SG-FLG 02250194-538 14" FLG 17700 40.0 63.0 14.3 36.0 1/2” NPT 02250194-594 28
FW-01500-FRHT-300-AD-SG-FLG 02250194-541 3” FLG 1500 18.0 46.0 6.0 30.0 1/2” NPT 02250194-595 2
FW-01900-FRHT-400-AD-SG-FLG 02250194-542 4” FLG 1900 18.0 46.0 6.0 30.0 1/2” NPT 02250194-595 3
FW-02500-FRHT-400-AD-SG-FLG 02250194-543 4” FLG 2500 21.0 46.0 6.0 30.0 1/2” NPT 02250194-595 4
FW-03800-FRHT-600-AD-SG-FLG 02250194-544 6” FLG 3800 23.0 50.0 8.7 31.5 1/2” NPT 02250194-595 6
FW-05000-FRHT-600-AD-SG-FLG 02250194-545 6” FLG 5000 23.0 51.0 10.0 31.7 1/2” NPT 02250194-595 8
FW-06500-FRHT-800-AD-SG-FLG 02250194-546 8” FLG 6500 29.0 53.4 10.0 32.8 1/2” NPT 02250194-595 10
FW-08300-FRHT-800-AD-SG-FLG 02250194-547 8" FLG 8300 30.0 55.0 10.0 32.9 1/2” NPT 02250194-595 14
FW-10000-FRHT-1000-AD-SG-FLG 02250194-548 10" FLG 10000 32.0 58.0 12.8 34.0 1/2” NPT 02250194-595 16
FW-12400-FRHT-1200-AD-SG-FLG 02250194-549 12" FLG 12400 32.0 60.0 14.6 35.0 1/2” NPT 02250194-595 18
FW-15000-FRHT-1400-AD-SG-FLG 02250194-550 14" FLG 15000 40.0 63.0 14.3 36.0 1/2” NPT 02250194-595 24
FW-17700-FRHT-1400-AD-SG-FLG 02250194-551 14" FLG 17700 40.0 63.0 14.3 36.0 1/2” NPT 02250194-595 28
FW-01500-H-300-AD-SG-FLG 02250194-554 3” FLG 1500 18.0 46.0 6.0 30.0 1/2” NPT 02250194-596 2
FW-01900-H-400-AD-SG-FLG 02250194-555 4” FLG 1900 18.0 46.0 6.0 30.0 1/2” NPT 02250194-596 3
FW-02500-H-400-AD-SG-FLG 02250194-556 4” FLG 2500 21.0 46.0 6.0 30.0 1/2” NPT 02250194-596 4
FW-03800-H-600-AD-SG-FLG 02250194-557 6” FLG 3800 23.0 50.0 8.7 31.5 1/2” NPT 02250194-596 6
FW-05000-H-600-AD-SG-FLG 02250194-558 6” FLG 5000 23.0 51.0 10.0 31.7 1/2” NPT 02250194-596 8
FW-06500-H-800-AD-SG-FLG 02250194-559 8” FLG 6500 29.0 53.4 10.0 32.8 1/2” NPT 02250194-596 10
FW-08300-H-800-AD-SG-FLG 02250194-560 8" FLG 8300 30.0 55.0 10.0 32.9 1/2” NPT 02250194-596 14
FW-10000-H-1000-AD-SG-FLG 02250194-561 10" FLG 10000 32.0 58.0 12.8 34.0 1/2” NPT 02250194-596 16
FW-12400-H-1200-AD-SG-FLG 02250194-562 12" FLG 12400 32.0 60.0 14.6 35.0 1/2” NPT 02250194-596 18
FW-15000-H-1400-AD-SG-FLG 02250194-563 14" FLG 15000 40.0 63.0 14.3 36.0 1/2” NPT 02250194-596 24
FW-17700-H-1400-AD-SG-FLG 02250194-564 14" FLG 17700 40.0 63.0 14.3 36.0 1/2” NPT 02250194-596 28
FW-01500-HR-300-AD-SG-FLG 02250194-557 3” FLG 1500 18.0 46.0 6.0 30.0 1/2” NPT 02250194-597 2
FW-01900-HR-400-AD-SG-FLG 02250194-568 4” FLG 1900 18.0 46.0 6.0 30.0 1/2” NPT 02250194-597 3
FW-02500-HR-400-AD-SG-FLG 02250194-569 4” FLG 2500 21.0 46.0 6.0 30.0 1/2” NPT 02250194-597 4
FW-03800-HR-600-AD-SG-FLG 02250194-570 6” FLG 3800 23.0 50.0 8.7 31.5 1/2” NPT 02250194-597 6
FW-05000-HR-600-AD-SG-FLG 02250194-571 6” FLG 5000 23.0 51.0 10.0 31.7 1/2” NPT 02250194-597 8
FW-06500-HR-800-AD-SG-FLG 02250194-572 8” FLG 6500 29.0 53.4 10.0 32.8 1/2” NPT 02250194-597 10
FW-08300-HR-800-AD-SG-FLG 02250194-573 8" FLG 8300 30.0 55.0 10.0 32.9 1/2” NPT 02250194-597 14
FW-10000-HR-1000-AD-SG-FLG 02250194-574 10" FLG 10000 32.0 58.0 12.8 34.0 1/2” NPT 02250194-597 16
FW-12400-HR-1200-AD-SG-FLG 02250194-575 12" FLG 12400 32.0 60.0 14.6 35.0 1/2” NPT 02250194-597 18
FW-15000-HR-1400-AD-SG-FLG 02250194-576 14" FLG 15000 40.0 63.0 14.3 36.0 1/2” NPT 02250194-597 24
FW-17700-HR-1400-AD-SG-FLG 02250194-577 14" FLG 17700 40.0 63.0 14.3 36.0 1/2” NPT 02250194-597 28
FW-01500-C-300-AD-SG-FLG 02250194-580 3” FLG 1500 18.0 46.0 6.0 30.0 1/2” NPT 02250194-599 2
FW-01900-C-400-AD-SG-FLG 02250194-581 4” FLG 1900 18.0 46.0 6.0 30.0 1/2” NPT 02250194-599 3
FW-02500-C-400-AD-SG-FLG 02250194-582 4” FLG 2500 21.0 46.0 6.0 30.0 1/2” NPT 02250194-599 4
FW-03800-C-600-AD-SG-FLG 02250194-583 6” FLG 3800 23.0 50.0 8.7 31.5 1/2” NPT 02250194-599 6
FW-05000-C-600-AD-SG-FLG 02250194-584 6” FLG 5000 23.0 51.0 10.0 31.7 1/2” NPT 02250194-599 8
FW-06500-C-800-AD-SG-FLG 02250194-585 8” FLG 6500 29.0 53.4 10.0 32.8 1/2” NPT 02250194-599 10
FW-08300-C-800-AD-SG-FLG 02250194-586 8" FLG 8300 30.0 55.0 10.0 32.9 1/2” NPT 02250194-599 14
FW-10000-C-1000-AD-SG-FLG 02250194-587 10" FLG 10000 32.0 58.0 12.8 34.0 1/2” NPT 02250194-599 16
FW-12400-C-1200-AD-SG-FLG 02250194-588 12" FLG 12400 32.0 60.0 14.6 35.0 1/2” NPT 02250194-599 18
FW-15000-C-1400-AD-SG-FLG 02250194-589 14" FLG 15000 40.0 63.0 14.3 36.0 1/2” NPT 02250194-599 24
FW-17700-C-1400-AD-SG-FLG 02250194-590 14" FLG 17700 40.0 63.0 14.3 36.0 1/2” NPT 02250194-599 28
