Section 8
PARTS LIST
45
8.4 AIR INLET SYSTEM
key part
number description number quantity
1 filter, air
(I)
409264 1
2 nut, hex flanged 5/16”--18 825305--283 4
3 screw , hex ser washer 5/16” x 3/4” 829705--075 4
4 support, air filter (air-cooled only) 02250047--269 1
5 support, air filter (water-cooled only) 02250056--087 1
6 band, mounting 14” 041062 2
7 clamp, hose 6” 242000 1
8 elbow, rubber reducing 6” to 5 1/2” 407458 1
9 clamp, hose 6 1/2” 040305 1
10 adapter, air inlet (air-cooled only) 02250047--270 1
11 adapter, air inlet (water-cooled only) 02250056--089 1
12 capscrew, hex GR5 3/4”--10 x 2” 829112--200 8
13 washer , springlock 3/4” 837812--188 8
14 connector, tube--M 1/4” x 1/8” 813604--125 1
15 gasket, 6 1/4” x 8 1/4” 040696 2
16 lever , inlet valve 020687 1
17 screw, set sq head 5/16” x 3/4”--18 02250112--197 1
18 valve, butterfly 02250118--520 1
19 adapter, air inlet 8” to 6” 250002--615 1
20 gasket, 8 1/2” x 10 1/2” 040422 1
(I)
For maintenance on air filter no. 409264, order primary replacement element no. 409853, and secondary re-
placement element no. 409854.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE SERIAL NUM BER OF COMPRESSOR
